Details:

The VS192A 2-Port 4K DisplayPort Splitter is the perfect solution for anyone who needs to send one source of DisplayPort high definition video to two DisplayPort displays. The VS192A can not only split but also expand DisplayPort audio/video signal on two DisplayPort monitors which is ideal for any multi-display application.

The VS192A is compatible with DisplayPort 1.2a and can support up to 4K resolution at 60 Hz, making it effective and ideal for use with all DisplayPort displays in home theater applications, as well as in corporate, educational and commercial settings.

Specifications:

Video Input

1 x DisplayPort Female (Black)

Video Output

2 x DisplayPort Female (Black)

Video

Compliance

DP 1.2a; HDCP 1.3

Max. Resolution

Up to 4096 x 2160 / 3840 x 2160 @ 60Hz

Max. Data Rate

21.6 Gbps (5.4 Gbps per lane)

Power 1 x DC Jack

Consumption 5 VDC, 1.185W

Environmental Operating Temperature 0-40°C

Storage Temperature -20 - 60°C

Humidity 0 - 80% RH, Non-Condensing

Physical Properties Housing Metal

Weight 0.30 kg

Dimensions (L x W x H) 12.50 x 8.00 x 25.00 cm
