Aten A/V Over Cat 5 Receiver With Cascade For VS1204T/1208T. Cascade Up To 10 Level

  • Part: 1377365
  • Model: VE172R-AT-U
$11.00

Availability

In Stock

Details:

ATEN VE-172R A/V Over Cat 5 Receiver is compatible with ATEN MDS Standard Plus Solution (VS-1204T/VS-1208T, VE-170T/VE-170R/VE-170RQ). It can cascade up to 10 levels make long distance transmissions up to 150m.

Compatible Transmitter Units:
VE-170T A/V Over Cat 5 Transmitter
VS-1204T A/V Over Cat 5 Transmitter
VS-1208T A/V Over Cat 5 Transmitter

Compatible Receiver Units:
VE-172R A/V Over Cat 5 Receiver with Cascade
VE-170R A/V Over Cat 5 Receiver
VE-170RQ A/V Over Cat 5 Receiver with Deskew

Specifications:

  • Video Output: Interface 1 x HDB-15 Female (Blue)
  • Impedance: 75 ?
  • Video: Max Bandwidth 300 MHz
  • Max Resolutions / Distance: Up to 1920 x 1200@30m; 1280 x 1024@150m
  • Audio Output: 1 x Mini Stereo Jack Female (Green)
  • Power: Connector:1 x DC Jack (Black) Consumption:5.3 VDC, 2.3W
  • Environment: Operating Temp. 0-50°C
  • Storage Temp.: -20 - 60°C
  • Humidity: 0-80% RH, Non-Condensing
  • Physical Properties: Housing Metal
  • Weight: 0.24 kg
  • Dimensions (L x W x H): 12.77 x 9.04 x 2.26 cm
