Aten Altusen 1 Local/1 Remote Console 32 Port Rackmount Usb-Ps/2 Cat5 KVM Over Ip Switch With Virtual

  • Part: 1378253
  • Model: KN1132V-AX-U
$8,134.00

Availability

In Stock

Details:

ATEN's 4th generation of KVM over IP switches exceed expectations. The KN1132V features superior video quality (Full HD resolution of 1920 x 1200), FIPS 140-2 with level 1 security standards and virtual media transmissions at twice the speed. The KN series provides local console and remote over IP access for users to monitor and access their entire data center over a network. In addition, it offers out-of-band access with external modem support for BIOS-level troubleshooting when the network is down.

With dual on-board NICs and dual power supplies, the KN series are built for reliability, to ensure 24/7 availability of remote access to all servers.

Package Contents

  • 1x KN1132V KVM over IP Switch
  • 2x SA0142 Serial Adapters (RJ45-F to DB9-M; DTE to DCE)
  • 2x Power Cords
  • 1x Mounting Kit
  • 2x Lok-U-Plugs
  • 1x Lok-U-Plug Installation Tool
  • 1x Foot Pad Set (4 pcs.)
  • 1x User Instructions

Specifications:

Computer Connections

  • Direct 32
  • Maximum 512 (via Cascade KVM Switches)

Console Connections

  • Remote 1
  • Local 1

Port Selection

  • Pushbuttons,
  • Hotkeys
  • GUI

Connectors

  • Console Ports
  • 2 x USB Female (Black)
  • 1 x DVI-D Female (White)
  • 1 x VGA HDB-15 (Blue)
  • 1 x RJ-45 Female (Black)
  • KVM Ports 32 x RJ-45 Female (Black)
  • USB Port 3 x USB Female (Black)
  • Audio 2 x Audio Jack Female (Pink; Green)
  • Laptop USB Console (LUC) Port
  • 1 x Mini-USB Female (Black)
  • PON 1 x RJ-45 Female (Black)
  • Serial 1 x RJ-45 Female (Black)
  • LAN Ports 2 x RJ-45 Female (Black)
  • Power 2 x IEC 60320/C14

Switches

  • Power 2 x Rocker Switches
  • Port Selection 2 x Pushbuttons
  • Reset 1 x Semi-recessed Pushbutton

LEDs

  • Online / Selected 32 (Green/Orange)
  • Power 2 (Blue)
  • Link 10 / 100 / 1000 Mbps 2 (Red/Orange/Green)

Emulation

  • Keyboard / Mouse PS/2; USB

Video

  • Local 1920 x 1200 @ 60Hz
  • Remote 1920 x 1200 @ 60Hz

Maximum Input Power Rating 100–240V~ ; 50-60Hz; 1A

Power Consumption

  • Single Power 110V/25.6W; 220V/26.5W
  • Dual Power 110V/15.46W; 220V/16.16W (per input)

Scan Interval 1 – 255 Sec

Environmental

  • Operating Temperature 0 - 40°C
  • Storage Temperature -20 - 60°C
  • Humidity 0 - 80% RH, Non-condensing

Physical Properties

  • Housing Metal
  • Dimensions (L x W x H) 43.36 x 41.21 x 4.40 cm
  • Weight 5.54 kg
