- General Information
- Manufacturer
- TP-LINK Technologies Co., Ltd
- Manufacturer Website Address
- http://www.tp-link.com.au
- Brand Name
- TP-Link
- Product Line
- VIGI
- Product Type
- Network Camera
Smart Detection
Receive notifications and check feeds when someone crosses a boundary,
enters an area you've set, or obstructs the camera.
Motion Detection
Get instant notifications when your camera detects motion.
Human Detection
Smarter security alerts focus on human movement instead of flying insects, small animals and leaves.
Line-Crossing
Set a boundary and receive an alert anytime a person crosses it from either or both directions.
Area Intrusion
Set customized activity zones around key areas for more focused monitoring.
Camera Tampering
Receive alerts when someone obstructs the camera.
SmartVid | Smart IR
Keeps objects from being under-rendered when far away or overexposed when close to camera at night.
Wide Dynamic Range
Adjusts for lighting contrast to minimize shadowing effects and renders images true to life.
3D DNR
Removes abnormal pixelation to provide clearer video and eliminate distortion.
VIGI Surveillance Solution
The VIGI professional surveillance system by TP-Link is dedicated to protecting the business that you've worked hard to build-whenever, wherever.
Outstanding functions, reliable quality guarantees, and simplified installation work together to ensure your business stays safe and sound.
- Technical Information
- HD Recording
- Yes
- Night Vision
- Yes
- Night Vision Distance
- 30 m
- Night Vision Type
- Infrared/Color
- Display & Graphics
- Image Sensor Type
- CMOS
- Colour Supported
- Colour
- Field of View
- Horizontal FOV: 79°, Vertical FOV: 43°, Diagonal FOV: 93°
- Effective Camera Resolution
- 4 Megapixel
- Video
- Video Formats
- H.265+
- H.265
- H.264+
- H.264
- H.264 (MP)
- H.264 HP
- H.265 (MP)
- Maximum Video Resolution
- 2560 x 1440
- Maximum Frame Rate
- 30 fps
- Lens
- Lens Type
- Fixed
- Maximum Focal Length
- 4 mm
- Lens Included
- Yes
- Lens Mount Type
- M12-mount
- Maximum Aperture
- f/1.6
- Network & Communication
- Connectivity Technology
- Wired
- Remote Management
- Yes
- Storage
- Storage Type
- Memory Card
- Interfaces/Ports
- Network (RJ-45)
- Yes
- Power Description
- Input Voltage
- 12 V DC
- Power Source Type
- DC
- PoE
- Physical Characteristics
- Form Factor
- Bullet
- Durability
- Weather Proof
- Water Proof
- Height
- 78 mm
- Width
- 70 mm
- Depth
- 174 mm
- Weight (Approximate)
- 195 g
- Environmental Conditions
- Minimum Operating Temperature
- -30°C
- Maximum Operating Temperature
- 60°C
- Miscellaneous
- Features
- Password Protection
- HTTPS Encryption
- Mirror
- Privacy Masking
- 3D Digital Noise Reduction
- Digital Wide Dynamic Range (D-WDR)
- Back Light Compensation (BLC)
- Cross Line Detection
- Human Detection
- Motion Detection
- Tamper Detection
- Region of Interest
- Built-in Microphone
- Built-in Speaker
- SD Card Local Storage
- Indoor/Outdoor
- Outdoor
- Ingress Protection Rating
- IP66
- Environmentally Friendly
- Yes
